WTI-1850

Industrial Touch Monitor

Features

  • Customization Service (NPI/DMS/CISO)
  • Rimless aluminum bezel, Ergonomic enclosure design
  • Front IP65 for waterproof and dustproof
  • Expandable LCD Selections (15.6”/18.5”/21.5”/23.8”)
  • PCAP multi-touch (10 points) supports higher sensitivity and allows wearing gloves
  • Multiple signal interfaces with HDMI, VGA & DP
  • VESA 100 x 100 wall mounting standard
WTIシリーズの産業用18.5インチタッチモニターは、2W + 2Wスピーカーとデュアルビデオ入力を内蔵しています。前面はIP65の防水等級を備え、標準の統合フレームデザインを採用しており、VESAマウントにも対応しています。これにより、簡単に設置でき、さまざまなアプリケーションに柔軟に対応可能です。

LCD 18.5”
Visible area (mm) 409.8 x 230.4
Max resolution 1366 x 768
Colors 16.7M
Brightness 450 cd/m2
Contrast 1000:1
Response time 8ms
View angle (U/D/L/R) Horizontal (R/L): 170

Vertical (U/D): 160

Video input 1x DP 1.2
1 x HDMI 1.4a
1 x VGA (D-sub 15 pin)
Power In DC 12V
USB 1 (Input for Touch)
Speaker 2 x 2W speaker
Touch Projected Capacitive touch
Touch screen hardness >=7H
Touch point 10 Points
Dimension 459.4 x 280 x 40mm
Weight 4.6kg
Operating temperature 0 ~ 50℃
