WTI-2380

Industrial Touch Monitor

Features

  • Customization Service (NPI/DMS/CISO)
  • Rimless aluminum bezel, Ergonomic enclosure design
  • Front IP65 for waterproof and dustproof
  • Expandable LCD Selections (15.6”/18.5”/21.5”/23.8”)
  • PCAP multi-touch (10 points) supports higher sensitivity and allows wearing gloves
  • Multiple signal interfaces with HDMI, VGA & DP
  • VESA 100 x 100 wall mounting standard
WTIシリーズ産業用タッチモニターは、2W + 2Wスピーカーとデュアルビデオ入力を内蔵しています。システムは、前面表面にIP65の防水等級を備えているだけでなく、標準の統合フレームデザインを採用し、VESAマウントに対応しています。これにより、簡単な設置が可能で、さまざまなアプリケーションに柔軟に対応できます。

LCD23.8”
Visible area (mm)527.04 x 296.46
Max resolution1920 x 1080
Colors16.7M
Brightness250 cd/m2
Contrast3000:1
Response time16ms
View angle (U/D/L/R)Horizontal (R/L): 89/89

Vertical (U/D): 89/89

Video input1x DP 1.2
1 x HDMI 1.4a
1 x VGA (D-sub 15 pin)
Power InDC 12V
USB1 (Input for Touch)
Speaker2 x 2W speaker
TouchProjected Capacitive touch
Touch screen hardness>=7H
Touch point10 Points
Dimension578.6 x 350.6 x 40mm
Weight7.1kg
Operating temperature0 ~ 40℃
